Rectangular Connectors(15102)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Applications | Mounting Type | Features | Base Product Number | Color | Termination | Ingress Protection | Note | Style | Height Above Board | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Connector Type | Pitch | Number of Rows | Row Spacing | Contact Finish | Contact Finish Thickness | Current Rating (Amps) | Contact Material | Material Flammability Rating | Contact Type | Pitch - Mating | Number of Positions | Row Spacing - Mating | Number of Positions Loaded | Shrouding | Fastening Type | Contact Length - Mating | Contact Length - Post | Overall Contact Length | Insulation Height | Contact Shape | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish - Post | Insulation Material | Insulation Color | Voltage Rating | Mated Stacking Heights | Contact Finish Thickness - Post | Wire Gauge | Contact Termination | Cable Termination | Wire Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MDF7-12DP-2.54DSA(55) | - |  |
6189 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0034-7-55 | EAR99 | 8536.69.4040 | 100 | Header | 2 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 12 | 0.100" (2.54mm) | All | Unshrouded | Push-Pull | 0.394" (10.00mm) | 0.118" (3.00mm) | 0.612" (15.54mm) | 0.100" (2.54mm) | Square | Tin | 39.4µin (1.00µm) | Tin | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
 |
MDF7-12P-2.54DS(56) | - | |
7310 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole, Right Angle | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0116-0-56 | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 12 | - | All | Unshrouded | Push-Pull | 0.292" (7.42mm) | 0.130" (3.30mm) | - | 0.157" (4.00mm) | Square | Gold | 30.0µin (0.76µm) | - | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
 |
MDF7-19P-2.54DSA(55) | - | |
6196 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0155-1-55 | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 19 | - | All | Unshrouded | Push-Pull | 0.394" (10.00mm) | 0.118" (3.00mm) | 0.612" (15.54mm) | 0.100" (2.54mm) | Square | Tin | 39.4µin (1.00µm) | Tin | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
 |
MDF7-20P-2.54DS(55) | - | |
9891 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole, Right Angle | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0172-0-55 | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 20 | - | All | Unshrouded | Push-Pull | 0.292" (7.42mm) | 0.130" (3.30mm) | - | 0.157" (4.00mm) | Square | Tin | 39.4µin (1.00µm) | Tin | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
 |
MDF7-22DP-2.54DSA | - | |
9364 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0093-6-00 | EAR99 | 8536.69.4040 | 100 | Header | 2 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 22 | 0.100" (2.54mm) | All | Unshrouded | Push-Pull | 0.394" (10.00mm) | 0.118" (3.00mm) | 0.612" (15.54mm) | 0.100" (2.54mm) | Square | Gold | 8.00µin (0.203µm) | - | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
|
MDF7-24P-2.54DS(55) | - | |
6333 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole, Right Angle | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0176-1-55 | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 24 | - | All | Unshrouded | Push-Pull | 0.292" (7.42mm) | 0.130" (3.30mm) | - | 0.157" (4.00mm) | Square | Tin | 39.4µin (1.00µm) | Tin | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
 |
MDF7-24P-2.54DSA(01) | - | |
2414 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0159-2-01 | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 24 | - | All | Unshrouded | Push-Pull | 0.394" (10.00mm) | 0.118" (3.00mm) | 0.612" (15.54mm) | 0.100" (2.54mm) | Square | Gold | 30.0µin (0.76µm) | - | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
|
MDF7-25P-2.54DSA(01) | - | |
5454 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0023-0-01 | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 25 | - | All | Unshrouded | Push-Pull | 0.394" (10.00mm) | 0.118" (3.00mm) | 0.612" (15.54mm) | 0.100" (2.54mm) | Square | Gold | 30.0µin (0.76µm) | - | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
|
MDF7-25P-2.54DSA(55) | - | |
8536 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bulk | Obsolete | -35°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Board | download | RoHS Compliant | 1 (Unlimited) | 547-0023-0-55 | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 25 | - | All | Unshrouded | Push-Pull | 0.394" (10.00mm) | 0.118" (3.00mm) | 0.612" (15.54mm) | 0.100" (2.54mm) | Square | Tin | 39.4µin (1.00µm) | Tin | Polybutylene Terephthalate (PBT) | Black | 250V | - | - | ||||||||||||||
 |
DF12B(3.0)-60DP-0.5V(86) | - | |
2008 | 0.00000000 | Hirose Electric Co Ltd | DF12 | Tape & Reel (TR) | Obsolete | Surface Mount | Solder Retention | 0.091" (2.30mm) | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | Header, Outer Shroud Contacts | 0.020" (0.50mm) | 2 | Gold | 8.00µin (0.203µm) | 60 | 3mm | |||||||||||||||||||||||||||||||||||||
 |
DF3EA-13P-2V(51) | 0.8820 | |
6948 | 0.00000000 | Hirose Electric Co Ltd | DF3 | Tape & Reel (TR) | Active | -55°C ~ 105°C | - | Surface Mount | Solder Retention | DF3E | Solder | - | Board to Board or Cable | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | Header | 1 | Varies by Wire Gauge | Brass | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 13 | - | All | Shrouded - 4 Wall | Push-Pull | - | - | - | 0.232" (5.90mm) | Circular | Gold | 8.00µin (0.203µm) | - | Polyamide (PA), Nylon | Beige | 250VAC | 7.5mm, 7.7mm, 8.4mm | - | ||||||||||||||
 |
MDF7C-25P-2.54DSA(37) | - | |
8536 | 0.00000000 | Hirose Electric Co Ltd | - | Bag | Obsolete | - | RoHS Compliant | 1 (Unlimited) | 26-MDF7C-25P-2.54DSA(37) | EAR99 | 8536.69.4040 | 1 | ||||||||||||||||||||||||||||||||||||||||||||||
 |
DF13-7P-1.25H(21) | 0.7000 | |
207 | 0.00000000 | Hirose Electric Co Ltd | DF13 | Tape & Reel (TR) | Obsolete | -35°C ~ 85°C | - | Surface Mount, Right Angle | Board Guide, Solder Retention | DF13 | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | Header | 1 | 1A | Brass | UL94 V-0 | Male Pin | 0.049" (1.25mm) | 7 | - | All | Shrouded - 4 Wall | Detent Lock | - | - | - | 0.142" (3.60mm) | Square | Tin | - | Tin | Polyamide (PA), Nylon | Beige | 150V | - | - | ||||||||||||||
|
GT25-28DP-2.2H(01) | - | |
7555 | 0.00000000 | Hirose Electric Co Ltd | - | Bulk | Obsolete | - | RoHS Compliant | 1 (Unlimited) | 775-0040-5-01 | EAR99 | 8536.69.4040 | 30 | ||||||||||||||||||||||||||||||||||||||||||||||
|
DF3EA-11P-2H(96) | 1.0757 | |
9512 | 0.00000000 | Hirose Electric Co Ltd | DF3 | Tape & Reel (TR) | Last Time Buy | -55°C ~ 105°C | - | Surface Mount, Right Angle | Solder Retention | Solder | - | Board to Board or Cable | - | 1,000 | Header | 1 | Varies by Wire Gauge | Brass | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 11 | - | All | Shrouded - 4 Wall | Push-Pull | - | - | - | 0.232" (5.90mm) | Circular | Tin | 8.00µin (0.203µm) | Tin | Polyamide (PA), Nylon | Natural | 250VAC | - | - | |||||||||||||||||||
 |
DF7-8P-3.96DSA(25) | - | |
7447 | 0.00000000 | Hirose Electric Co Ltd | DF7 | Tray | Obsolete | -35°C ~ 85°C | - | Through Hole | Board Guide | Solder | - | Board to Cable/Wire | download | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 35 | Header | 1 | - | Copper Alloy | UL94 V-0 | Male Pin | 0.156" (3.96mm) | 8 | - | All | Shrouded - 4 Wall | Latch Holder | 0.276" (7.00mm) | 0.138" (3.50mm) | - | 0.508" (12.90mm) | Square | Tin | - | Tin | Polyamide (PA), Nylon, Glass Filled | Beige | - | 21.5mm | - | |||||||||||||||
 |
BM29B0.6-4DS/2-0.35V(51) | 0.7300 | |
44 | 0.00000000 | Hirose Electric Co Ltd | BM29 | Tape & Reel (TR) | Active | Surface Mount | - | BM29B | 0.024" (0.61mm) | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 20,000 | Receptacle, Center Strip Contacts | 0.014" (0.35mm) | 2 | Gold | 1.97µin (0.050µm) | 4 (2 + 2 Power) | 0.6mm | ||||||||||||||||||||||||||||||||||||
|
DF13EA-30DP-1.25V(83) | - | |
4319 | 0.00000000 | Hirose Electric Co Ltd | * | Bulk | Obsolete | - | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||
|
DF63M-4P-3.96DS(01) | 5.1030 | |
1971 | 0.00000000 | Hirose Electric Co Ltd | EnerBee™ DF63 | Bag | Active | -55°C ~ 105°C | - | Through Hole, Right Angle | Board Guide, Glow Wire Compliant | DF63 | Solder | - | Board to Cable/Wire | - | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Header | 1 | Varies by Wire Gauge | Brass | UL94 V-0 | Male Pin | 0.156" (3.96mm) | 4 | - | All | Shrouded - 4 Wall | Latch Holder | - | 0.138" (3.50mm) | - | 0.354" (9.00mm) | Square | Gold | 8.00µin (0.203µm) | Tin | Polybutylene Terephthalate (PBT), Glass Filled | Black | 600VAC/DC | - | 39.4µin (1.00µm) | ||||||||||||||
|
GT36-1B/1S-HU(D) | 0.3647 | |
9964 | 0.00000000 | Hirose Electric Co Ltd | GT36 | Bulk | Last Time Buy | - | - | - | GT36 | - | - | - | RoHS Compliant | Not Applicable | 786-0061-9-00 | EAR99 | 8538.90.8180 | 100 | - | - | - | - | - | - | - | - | ||||||||||||||||||||||||||||||||
|
GT25-24DP-2.2H(55) | - | |
9565 | 0.00000000 | Hirose Electric Co Ltd | * | Tape & Reel (TR) | Active | - | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | ||||||||||||||||||||||||||||||||||||||||||||||||
|
MDF7-12P-2.54DS(95) | 0.9702 | |
7826 | 0.00000000 | Hirose Electric Co Ltd | MDF7 | Bag | Active | -35°C ~ 85°C | - | Through Hole, Right Angle | - | MDF7 | Solder | - | Board to Cable/Wire | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 12 | - | All | Unshrouded | Push-Pull | 0.293" (7.45mm) | 0.130" (3.30mm) | - | 0.157" (4.00mm) | Square | Tin | - | Tin | Polybutylene Terephthalate (PBT) | Black | 250VAC | - | - | ||||||||||||||
 |
MDF6-18DP-3.5DSA(05) | - | |
7355 | 0.00000000 | Hirose Electric Co Ltd | MDF6 | Bulk | Obsolete | -30°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | 547-0090-8-05 | EAR99 | 8536.69.4040 | 100 | Header | 2 | - | Brass | UL94 V-0 | Male Pin | 0.138" (3.50mm) | 18 | 0.197" (5.00mm) | All | Shrouded - 4 Wall | Latch Holder | 0.220" (5.59mm) | 0.138" (3.50mm) | - | 0.512" (13.00mm) | Square | Tin-Copper | 39.4µin (1.00µm) | - | Polyamide (PA), Nylon | White | 300V | - | - | ||||||||||||||
 |
DF14-6P-1.25H(65) | 1.2300 | |
249 | 0.00000000 | Hirose Electric Co Ltd | DF14 | Tube | Active | -35°C ~ 85°C | - | Surface Mount, Right Angle | Board Guide, Solder Retention | Solder | - | Board to Cable/Wire | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 39 | Header | 1 | 1A | Brass | UL94 V-0 | Male Pin | 0.049" (1.25mm) | 6 | - | All | Shrouded - 4 Wall | Push-Pull | 0.087" (2.20mm) | - | - | 0.098" (2.50mm) | Square | Gold | 3.94µin (0.100µm) | Gold | Polyamide (PA), Nylon | Beige | 150VAC | - | 3.94µin (0.100µm) | |||||||||||||||
 |
DF12B(3.5)-36DP-0.5V(86) | - | |
1635 | 0.00000000 | Hirose Electric Co Ltd | DF12 | Tape & Reel (TR) | Obsolete | Surface Mount | Solder Retention | 0.110" (2.80mm) | download | RoHS Compliant | 1 (Unlimited) | 537-0331-5-86 | EAR99 | 8536.69.4040 | 1,000 | Header, Outer Shroud Contacts | 0.020" (0.50mm) | 2 | Gold | 8.00µin (0.203µm) | 36 | 3.5mm | ||||||||||||||||||||||||||||||||||||
|
HIF3MAW-26PA-2.54DS(63) | 2.9190 | |
9347 | 0.00000000 | Hirose Electric Co Ltd | HIF3MAW | Tray | Active | -55°C ~ 85°C | - | Through Hole, Right Angle | Keying Slot, Mounting Flange | HIF3 | Solder | - | Board to Cable/Wire | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 120 | Header | 2 | 1A | Brass | UL94 V-0 | Male Pin | 0.100" (2.54mm) | 26 | 0.100" (2.54mm) | All | Shrouded - 4 Wall | Latch Lock/Eject Hooks | 0.236" (6.00mm) | 0.118" (3.00mm) | - | 0.335" (8.51mm) | Square | Gold | 5.90µin (0.150µm) | Tin | Polybutylene Terephthalate (PBT) | Black | 200VAC | - | 78.7µin (2.00µm) | ||||||||||||||
|
DF63-5P-3.96DSA(01) | 5.1000 | |
1481 | 0.00000000 | Hirose Electric Co Ltd | EnerBee™ DF63 | Bulk | Last Time Buy | -55°C ~ 105°C | - | Through Hole | Board Guide | DF63 | Solder | - | Board to Cable/Wire | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Header | 1 | Varies by Wire Gauge | Brass | UL94 V-0 | Male Pin | 0.156" (3.96mm) | 5 | - | All | Shrouded - 4 Wall | Latch Holder | - | 0.150" (3.81mm) | - | 0.394" (10.00mm) | Square | Gold | 8.00µin (0.203µm) | Tin | Polybutylene Terephthalate (PBT), Glass Filled | Black | 600VAC/DC | - | 39.4µin (1.00µm) | ||||||||||||||
 |
DF13-15P-1.25DSA(05) | - | |
100 | 0.00000000 | Hirose Electric Co Ltd | DF13 | Bulk | Active | -35°C ~ 85°C | - | Through Hole | - | DF13 | Solder | - | Board to Cable/Wire | - | 1 (Unlimited) | 26-DF13-15P-1.25DSA(05) | EAR99 | 8536.69.4040 | 1 | Header | 1 | 1A per Contact | Brass | UL94 V-0 | Male Pin | 0.049" (1.25mm) | 15 | - | All | Shrouded - 4 Wall | Detent Lock | - | 0.091" (2.30mm) | - | 0.169" (4.30mm) | Square | Tin | - | Tin | Polyamide (PA), Nylon | Beige | 150V | - | - | ||||||||||||||
 |
DF51K-12DP-2DSA(805) | 1.2900 | |
465 | 0.00000000 | Hirose Electric Co Ltd | SignalBee™ DF51K | Bulk | Active | -55°C ~ 105°C | General Purpose, Industrial, Medical | Through Hole | - | DF51K | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | 26-DF51K-12DP-2DSA(805) | EAR99 | 8536.69.4040 | 100 | Header | 2 | Varies by Wire Gauge | Brass | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 12 | 0.079" (2.00mm) | All | Shrouded - 4 Wall | Latch Holder | - | 0.118" (3.00mm) | - | 0.331" (8.40mm) | Square | Gold | 3.94µin (0.100µm) | Gold | Polybutylene Terephthalate (PBT), Glass Filled | Black | 250VAC/DC | - | 3.94µin (0.100µm) | |||||||||||||
 |
HIF3BA-50PD-2.54R-MC(63) | 17.4600 | |
43 | 0.00000000 | Hirose Electric Co Ltd | HIF3B | Bulk | Active | Free Hanging (In-Line) | Feed Through, Polarizing Key, Strain Relief | HIF3 | Black | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 60 | Plug | 0.100" (2.54mm) | 2 | 0.100" (2.54mm) | Gold | 7.87µin (0.200µm) | Male Pin | 50 | Latch Lock/Eject Hooks | 28 AWG | IDC | Ribbon Cable |
